Exmark NAVIGATOR Parts Manual

ELECTRICAL GROUP
21
Item Part No. Description Qty.
1 1-513051 Switch, N.O........................................... 1
2 1-513152 Switch, N.C. .......................................... 1
3 1-513180 Plate, Switch ......................................... 1
4 1-513374 Meter, Hour........................................... 1
5 1-513747 Decal, Battery ....................................... 1
6 1-522424-03 Wld, Mount Seat Spring ........................ 1
7 1-523415 Spring ................................................... 1
8 109-2407 Insulator, Battery................................... 1
9 1-543393 Insulator, Solenoid ................................ 1
10 1-543792 Wingnut, Nyloc 1/4-20........................... 2
11 1-633111 Switch, N.C. .......................................... 2
12 1-633181 Plate, Tapped........................................ 4
13 1-643312 Clip, Loom 5/8....................................... 3
14 109-2923 Asm, Positive Battery Cable.................. 1
15 1-643267 Indicator, Red Led................................. 1
16 1-643275 Relay, 12VDC 40 Amp .......................... 3
17 32128-33 Nut, Whizlock 1/4-20............................. 7
18 103-0498 Nut, Ignition........................................... 1
19 1-807513 Bolt, Carriage #10-24 x 1/2.................... 2
20 100-6186 Module, Seat Delay............................... 1
21 103-0205 Alarm, Dual Tone 12VDC...................... 2
Item Part No. Description Qty.
22 109-4736 Asm, Switch W/Nut............................... 1
23 103-2106 Key, Exmark Logo................................. 1
1-603511 Key, Ignition.......................................... 1
24 103-1312 Bolt, Hold Down .................................... 2
25 1-816003 Fuse, 30 Amp ....................................... 1
26 103-9470 Asm, Battery Hold Down W/Decal ........ 1
27 1-816001 Fuse, 20 Amp ....................................... 2
28 103-8354 Cable, Battery (+).................................. 1
29 103-8355 Cable, Ground (-).................................. 1
30) 109-4270 Harness, Wiring.................................... 1
31) 103-8800 Harness, Hopper Wire .......................... 1
32 321-4 Screw, HH 1/4-20 x 3/4......................... 7
33 103-8528 Asm, Hopper Switch Actuator............... 1
34 1-303287 Tie, Cable 5 1/2 (Small) ........................ 1
35 322-50 Screw, HH 5/16-18 x 7 1/2.................... 1
36 3217-6 Nut, Hex 5/16-18................................... 1
37 3256-2 Washer, 1/4 Std.................................... 5
38 3290-134 Screw, HH Machine 10-24 x 5/8............ 2
39 3290-500 Screw, PPH #10-24 x 5/8...................... 8
40 3296-2 Nut, Nyloc #10-24................................. 4
41 3296-29 Nut, Nyloc 5/16-18................................ 1
X Use dielectric grease on all wiring harness connectors.
 Assembly includes items #8, #9, and #28.

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
