Exmark NAVIGATOR Parts Manual

MAIN FRAME GROUP
3
Item
Part No.
Description Qty.
1 103-8383 Bolt, Seat Cushion .................................5
2 1-633060 Spacer ...................................................2
3 1-633396 Clip, Loom 5/8........................................1
4 1-633508 Washer, Spring Disk..............................6
5 1-633585 Bearing, Cone Tapered Roller................2
6 103-9483 Asm, Seat Frame W/Decal ....................1
7 1-807513 Bolt, Carriage #10-24 x 1/2 ....................4
8 5-0652 Spacer ...................................................4
9 103-0063 Seal, Double Lip.....................................2
10 103-2768 Guard, Seal............................................2
11V 103-3051 Spacer, Nut............................................2
12 103-3351-03 Wld, Rear Caster Fork ...........................1
13 103-3520 Seat, Back .............................................1
14 109-2008 Seat, Bottom..........................................1
15 109-4306 Asm, Mainframe W/Decals ....................1
16 103-4155 Pin, Lynch..............................................2
17 103-4318 Wheel ....................................................2
18 1-303287 Tie, Cable 5 1/2 (Small) .........................4
19 103-4362-03 Wld, Seat Frame Std .............................1
20 109-4641 Cable, Control Throttle...........................1
21 103-5181 Link, Lower Seat Stop............................1
22 103-5302 Axle, Caster ...........................................1
23 103-5496 Mount, Vibration Rubber ........................4
24 103-6596-03 Wld, Push Rod.......................................2
25 103-7738 Screw, HH 1/2-13 x 13...........................1
26 103-8143 Console, RH ..........................................1
27 103-8146 Console, LH...........................................1
28 109-4639 Asm, Control Panel W/Decals................1
29 103-8451 Decal, Ignition/Speed Control.................1
30 103-8563 Link, Seat...............................................1
Item
Part No.
Description Qty.
31 109-4638 Decal, Console ...................................... 1
32 103-9027 Seal, Grease..........................................1
33 103-9028 Cone, Bearing Taper Roller ................... 2
34 103-9029 Cup, Bearing Tapered Roller .................2
35 103-9032 Decal, Service Aid ................................. 1
36 103-9034 Decal, Clutch Adjustment ......................1
37 103-9057 Cap, Grease..........................................1
38 242-50 Nut, Lug 1/2-20...................................... 8
39 322-2 Screw, HH 5/16-18 x 5/8........................ 6
40 322-5 Screw, HH 5/16-18 x 1...........................3
41 323-14 Screw, HH 3/8-16 x 3.............................2
42 325-17 Screw, HH 1/2-13 x 4.............................2
43 3231-27 Bolt, Carriage 3/8-16 x 7/8..................... 1
44 3256-23 Washer, 5/16 SAE................................. 6
45 3256-8 Washer.................................................. 1
46 3296-2 Nut, Nyloc #10-24.................................. 4
47 3296-23 Nut, Nyloc 1/2-13...................................1
48 3296-29 Nut, Nyloc 5/16-18................................. 3
49 3296-39 Nut, Nyloc 3/8-16...................................3
50 3296-51 Nut, Nyloc 3/4-10...................................1
51 103-5305 Asm, Wheel Tire & Brg 13x8.00-6 SP.... 1
52 32128-20 Nut, Whizlock 5/16-18 ........................... 8
53 32128-49 Nut, Whizlock 1/2-13 .............................2
54 109-2006 Asm, Seat W/Decal ............................... 1
55 103-9494 Asm, Rear Caster Wheel W/Axle...........1
56 109-4640 Cable, Control Choke ............................1
57 103-4319 Asm, Wheel & Tire 18 x 10.50-10.......... 2
103-4321 Asm, Wheel & Tire 18 x 8.50-10............ 2
58 105-1945 Tire, 18 X 10.5-10.................................. 2
103-4320 Tire, 18 X 8.50-10.................................. 2
Exmark black touch up spray paint – Gloss black
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on spacer nut, item #11.

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
