HOPPER GROUP
17
Item
Part No.
Description
Qty.
1 1-543963 Bumper, Rubber.....................................2
2 1-633068 Spacer ...................................................2
3 103-5045-03 Brace, Side............................................2
4 109-4086 Asm, Hopper Frame...............................1
5 103-5426 Stud, Ball 13mm ....................................2
6 103-5736-03 Channel, Screen (RH)............................1
7 103-5746 Shock, Gas Tension...............................2
8 103-5749-03 Panel, Hinge (LH) ..................................1
9 103-5751-03 Panel, Hinge (RH)..................................1
10 103-5752 Stud, Ball 10mm ....................................4
11 103-5772-03 Brace, Top .............................................1
12 103-5774-03 Channel, Screen (LH) ............................1
13 103-9457 Asm, Hopper..........................................1
14 103-6022-03 Channel, Hopper Frame.........................1
15 103-6025 Shield, Trailing.......................................1
16 103-7035-03 Channel, Screen Front...........................1
17 109-4019 Guard, Damper ......................................2
18 103-7824 Insulation, Foam Pad Rear ....................1
19 103-7825 Insulation, Foam Pad Front....................1
20 103-8324 Clip, Retainer-10mm ..............................4
Item
Part No.
Description
Qty.
21 103-8325 Clip, Retainer-13mm.............................. 2
22 321-2 Screw, HH 1/4-20 x 1/2.......................... 4
23 323-6 Screw, HH 3/8-16 x 1............................. 2
24 3229-2 Bolt, Carriage 1/4-20 x 1........................4
25 3229-4 Bolt, Carriage 1/4-50 x 1 1/2..................6
26 107069 Nut, Retainer ......................................... 4
27 3256-24 Washer, 3/8 SAE................................... 6
28 3256-3 Washer, 5/16 Std................................... 4
29 3296-39 Nut, Nyloc 3/8-16...................................6
30 3296-42 Nut, Nyloc 1/4-20...................................29
31 32105-32 Screw, Truss HD 1/4-20 x 1................... 30
32 32128-20 Nut, Whizlock 5/16-18 ........................... 4
33 32128-33 Nut, Whizlock 1/4-20 ............................. 39
34 1-513762 Clip, Loom 1/2 ....................................... 1
35 33005-00 Nut, Hex M10-1.5 Flg............................. 2
36 614672 Screw, Shoulder 3/8-16 x 1.295............. 2
37 103-5425 Shock, Gas Compression...................... 1
38 109-0715 Kit, Damper W/Clips .............................. 2
39 109-0716 Kit, Damper W/Clips .............................. 1
Reference page 20 for remainder of items included in hopper assembly
Includes items: 1, 18, 19, 32 and frame weldment.
