Exmark NAVIGATOR Parts Manual

HOPPER GROUP (cont.)
19
Item Part No. Description Qty.
1 1-303435 Washer, Spring Disk 1/4 ........................3
2 109-3854 Kit, Fill Sensor Wire ...............................1
3 1-513762 Clip, Loom 1/2........................................4
4 1-543296 Grommet................................................1
5 1-303335 Tie, Plastic.............................................1
6 109-3955 Door, 9.5 Bushel Hopper........................1
7 103-5745-03 Panel, Hopper Screen............................1
8 109-4253 Asm, Door Pivot W/Decal (LH)...............1
9 109-4254 Wld, Door Pivot W/Decal (RH)...............1
10 103-6024 Decal, Exmark Logo...............................1
11 109-3648 Wld, Switch Mount .................................1
12 103-6067-03 Bracket, Motor (LH)................................1
13 103-6068-03 Bracket, Motor (RH)...............................1
14 103-7048-03 Panel, Screen Extend ............................1
15 109-4153-03 Wld, Door Support .................................1
16 103-7085-03 Plate, Switch..........................................1
17 103-7098-03 Handle, Screen (LH) ..............................1
18 103-7099-03 Handle, Screen (RH)..............................1
19 109-3650-03 Wld, Diffuser..........................................1
20 103-9466 Asm, Fill Sensor.....................................1
21 109-0717 Asm, Hopper Screen..............................1
22 321-4 Screw, HH 1/4-20 x 3/4..........................5
23 103-8203-03 Guide, Screen........................................2
24 1-613235 Washer ..................................................2
Item Part No. Description Qty.
25 103-8444 Decal, Pinch Point .................................2
26 103-8680 Deflector, Discharge Chute.................... 1
27 103-8789 Flag, Fill Sensor.....................................2
28 109-3853 Motor .....................................................1
29 103-9456 Asm, Door Hopper.................................1
30 321-2 Screw, HH 1/4-20 x 1/2..........................19
31 322-4 Screw, HH 5/16-18 x 7/8........................ 4
32 329-4 Screw, HH 1/4-28 x 3/4.......................... 3
33 103-9457 Asm, Hopper..........................................1
34 3230-23 Bolt, Carriage 5/16-18 x 3/4...................6
35 3250-48 Screw, PPH #10-24 x 1 3/4.................... 2
36 3256-2 Washer, 1/4 Std.....................................17
37 9107622 Screw, PPH #6-32 x 5/8......................... 2
38 3256-23 Washer, 5/16 SAE................................. 4
39 32122-30 Screw, Truss HD #10-24 X 1/2 ..............2
40 109-1063 Screw, Wing 1/4-20 x 3/4.......................3
41 3296-2 Nut, Nyloc #10-24.................................. 4
42 3296-42 Nut, Nyloc 1/4-20................................... 5
43 3296-9 Nut, Nyloc #6-32 Thin............................2
44 32105-32 Screw, Truss HD 1/4-20 x 1...................6
45 107069 Nut, Retainer-Panel 1/4-20 .................... 5
46 32128-20 Nut, Whizlock 5/16-18............................8
47 32128-33 Nut, Whizlock 1/4-20 .............................27
48 32122-42 Screw, Truss HD 1/4-20 x 1/2................4
Reference page 18 for remainder of items included in hopper assembly.

Exmark NAVIGATOR Specifications

General

Drive System	Hydrostatic
Deck Construction	Fabricated
Transmission	Hydrostatic
Deck Material	Steel
Turning Radius	Zero-turn
Cutting Width	42 in
Blade Tip Speed	18, 500 fpm
Engine Type	V-Twin
