Exmark VANTAGE S Series User Manual

Specications
Tires&Wheels
Drive
FrontCaster
Pneumatic
(Air-Filled)
Semi-
Pneumatic
Quantity
22
TreadKendaK500
Smooth
Size18x8.50–811x4.00-5
PlyRating
4
Pressure
14psi
(97kPa)
CuttingDeck
•CuttingWidth:36inches(91.4cm)
•Discharge:Side
•BladeSize:(2ea.):18.00inches(45.7cm)
•BladeSpindles:Solidsteelspindleswith1.00inch
(25.4mm)I.D.bearings.
•DeckDrive:
–Electricclutchmountedonengineshaft.
–Bladesdrivenbyonebelt(w/self-tensioning
idlers).
•Deck:Fulloatingdeckisattachedtosupport
frame,removableforservice.Deckdesignallows
forbagging,mulchingorsidedischarge.
•DeckDepth:5.0inches(12.7cm)
•CuttingHeightAdjustment:
Adjustsfrom1inch(2.5cm)to5inches(12.7cm)
in1/4inch(6.4mm)increments
•MulchingKit:Optional
•Bagger:Optional
Dimensions
OverallWidth:
DeectorUp39.1inches(99.3cm)
DeectorDown48.0inches(121.9cm)
OverallLength:
PlatformUp61.5inches(156.2cm)
PlatformDown74.0inches(188.0cm)
OverallHeight:
51.5inches(130.8cm)
TreadWidth:(OutsidetoOutsideof
Tires,Widthwise)
37.6inches(95.5cm)
CurbWeight:
800lb(363kg)
Note:Weightswillvaryslightlydependingonengine.
TorqueRequirements
BoltLocation
Torque
CutterHousingSpindle
Nut
130-160ft-lb
(176-217N-m)
BladeMountingBolt
(lubricatewithanti-seize)
50-60ft-lb(68-81N-m)
EngineDeck/Mower
DeckSupportMount
Bolts
30-35ft-lb(41-47N-m)
EngineMountingBolts
30-35ft-lb(41-47N-m)
WheelLugNuts
85-105ft-lb(115-142
N-m)
WheelHubNuts175-225ft-lb
(237-305N-m)
WheelMotorMounting
Bolts
67-83ft-lb(91-113N-m)
15
