Operation
ProductOverview
Figure3
1.Platform
4.Motioncontrollevers
2.FuelCap5.EngineControls
3.Height-of-Cut
Adjustment
6.ParkBrakeLever
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Controls
MotionControlLevers
Themotioncontrollevers,locatedoneachsideofthe
topconsole,controltheforwardandreversemotion
ofthemachine.
Movingtheleversforwardorbackwardturns
thewheelonthesamesideforwardorreverse
respectively.Wheelspeedisproportionaltothe
amounttheleverismoved.
Figure4
1.LHMotioncontrollever6.Neutral
2.RHMotioncontrollever7.Forward
3.RHMotioncontrol
leverinPTOdisengage
position
8.Frontreference/Speed
controlbar
4.Reverse
9.Frontofunit
5.Rearreferencebar
Whenthemotioncontrolleversareintheneutral
position,theLCDindicatorappearsinthemessage
displayonthefrontcontrolconsole(seeFigure5and
Figure7).
Whenthemotioncontrolleversareintheneutral
positionandtheRHmotioncontrolleverismoved
intothePTOdisengageposition,themowerblades
willdisengage.
16
