Exmark VANTAGE S Series User Manual

Operation
Pullthehandlerearwardtoraisethecuttingdeck.
Allowthehandletomoveforwardtolowerthe
cuttingdecktothecutheightthathasbeenset.
Pullthehandlerearwardandtotherighttolatch
thecuttingdeckintotheraisedtransportposition
(Figure6).
Pre-Start
Fillfueltankonlevelground.SeeFuel
RecommendationsintheSpecicationssectionfor
additionalgasolineinformation.
DoNotaddoiltogasoline.
DoNotoverllfueltank.Fillthefueltanktothe
bottomofthellerneck.Theemptyspaceinthe
tankallowsgasolinetoexpand.Overllingmayresult
infuelleakageordamagetotheengineoremission
system.
Makesureyouunderstandthecontrols,their
locations,theirfunctions,andtheirsafety
requirements.
RefertotheMaintenancesectionandperformallthe
necessaryinspectionandmaintenancesteps.
OperatingInstructions
OpentheFuelShut-OffValve
Rotatethevalveandalignwiththefuellinetoopen.
StartingtheEngine
1.LeavetheLHmotioncontrolleverinneutraland
theRHleverinthePTOdisengageposition(see
Figure4).
2.Pulltheparkingbrakeleverrearwardtoengage
theparkingbrake.
3.Pushin(down)onthePTOswitchtothe
“disengage”position.
4.Placethethrottlemidwaybetweenthe“SLOW”
and“FAST”positions.
5.Onacoldengine,pushthechokeleverforward
intothe“ON”position.
Onawarmengine,leavethechokeinthe“OFF”
position.
6.Turnignitionswitchtothe“START”position.
Releasetheswitchassoonastheenginestarts.
Important:DoNotcranktheengine
continuouslyformorethantensecondsata
time.Iftheenginedoesnotstart,allowa60
secondcool-downperiodbetweenstarting
attempts.Failuretofollowtheseguidelines
canburnoutthestartermotor.
7.Ifthechokeisinthe“ON”position,gradually
returnchoketothe“OFF”positionastheengine
warmsup.
PTOEngagement
DANGER
Therotatingbladesunderthemowerdeckare
dangerous.Bladecontactcancauseserious
injuryorkillyou.
DoNotputhandsorfeetunderthemoweror
mowerdeckwhenthebladesareengaged.
DANGER
Anuncovereddischargeopeningwillallow
objectstobethrowninanoperator’sor
bystander’sdirection.Also,contactwiththe
bladecouldoccur.Thrownobjectsorblade
contactcancauseseriousinjuryordeath.
Neveroperatethemowerwiththedischarge
deectorraised,removed,oralteredunlessthere
isagrasscollectionsystemormulchkitinplace
andworkingproperly.
ThePTOswitchengagesthecuttingblades.Besure
allpersonsareclearofmowerdeckanddischarge
areabeforeengagingthePTO.
1.Setthrottleto“MIDWAY”position.
2.Releasetheparkingbrake.
3.Movetherightsidemotioncontrollevertothe
center,operateposition.
4.Continueholdingtherightsidemotioncontrol
leverinthecenter,operatepositionandpullup
onthebladecontrolswitch(PTO)andrelease.
Theclutchshouldengageandthemowerblades
beginrotating.
5.Placethethrottleinthe“FAST”positiontobegin
mowing.
19
