Troubleshooting
Troubleshooting
Important:Itisessentialthatalloperatorsafetymechanismsbeconnectedandinproperoperating
conditionpriortomoweruse.
Whenaproblemoccurs,donotoverlookthesimplecauses.Forexample:startingproblemscouldbecaused
byanemptyfueltank.
Thefollowingtablelistssomeofthecommoncausesoftrouble.DoNotattempttoserviceorreplacemajor
itemsoranyitemsthatcallforspecialtimingofadjustmentsprocedures(suchasvalves,governor,etc.).Have
thisworkdonebyyourEngineServiceDealer.
Note:WhendisconnectingelectricalconnectorsDoNotpullonthewirestoseparatetheconnectors.
ProblemPossibleCauseCorrectiveAction
1.PTOisengaged.
1.DisengagethePTO.
2.Oneofthespeedcontrolleversarenot
inneutralposition.
2.Ensurethespeedcontrolleverisinthe
neutralposition.
3.Batterydoesnothaveafullcharge.
3.
Chargethebattery.SeeCheckBattery
ChargeandRecommendedJump
StartingProceduresectionsin
Maintenance.
4.Electricalconnectionsarecorroded,loose
orfaulty.
4.Checktheelectricalconnectionsfor
goodcontact.Cleanconnectorterminals
thoroughlywithelectricalcontactcleaner,
applydielectricgreaseandreconnect.
5.Fuseisblown.5.Replacetheblownfuse.
6.NeutralLCDindicatordoesnot
illuminate.
6.Checkreedswitch.
Starterdoesnotcrank.
7.Relayorswitchisdefective.7.ContactanAuthorizedServiceDealer.
1.Fueltankisempty.1.Fillthefueltank.
2.Fuelshutoffvalveisclosed.
2.Openthefuelshutoffvalve.
3.Thethrottleandchokearenotinthe
correctposition.
3.Besurethethrottlecontrolismidway
betweenthe“SLOW”and“FAST”
positions,andthechokeisinthe“ON”
positionforacoldengineorthe“OFF”
positionforawarmengine.
4.Dirtinfuellter.4.Replacethefuellter.
5.Dirt,water,orstalefuelisinthefuel
system.
5.ContactanAuthorizedServiceDealer.
6.Aircleanerisdirty.
6.Cleanorreplacetheaircleanerelement.
7.Electricalconnectionsarecorroded,loose
orfaulty.
7.Checktheelectricalconnectionsfor
goodcontact.Cleanconnectorterminals
thoroughlywithelectricalcontactcleaner,
applydielectricgreaseandreconnect.
8.Relayorswitchisdefective.8.ContactanAuthorizedServiceDealer.
9.Faultysparkplug.
9.Clean,adjustorreplacesparkplug.
Enginewillnotstart,startshard,orfailsto
keeprunning
10.Sparkplugwireisnotconnected.
10.Checkthesparkplugwireconnection.
1.Engineloadisexcessive1.Reducethegroundspeed.
2.Aircleanerisdirty.
2.Cleanorreplacetheaircleanerelement.
3.Oillevelinthecrankcaseislow.
3.Addoiltothecrankcase.
4.Coolingnsandairpassagesforthe
engineareplugged.
4.Removetheobstructionsfromthe
coolingnsandairpassages.
5.Ventsystemlterplugged.5.Inspectventlter;replaceifdirty.
6.Dirtinfuellter.6.Replacethefuellter.
Enginelosespower
7.Dirt,water,orstalefuelisinthefuel
system.
7.ContactanAuthorizedServiceDealer.
43
