Exmark VANTAGE S Series User Manual

Operation
ChokeControl
Locatedonthefrontcontrolconsolerightofthe
PTOengagementswitch.
Thechokeisusedtoaidinstartingacoldengine.
Movingthechokeleverforwardwillputthechokein
the“ON”positionandmovingthechokelevertothe
rear,tothedetent,willputthechokeinthe“OFF”
position.DoNotrunawarmenginewithchokein
the“ON”position.
Figure5
1.Choke
8.Fuelgauge
2.RHMotioncontrollever
9.PTOengagementswitch
3.LHMotioncontrollever10.Throttle
4.FrontReference/Speed
ControlBar
11.Decklifthandle
5.Parkbrakelever12.Fuelcap
6.Messagedisplay
13.Height-of-cutpin
7.Ignitionswitch
14.Platformlatch
ThrottleControl
LocatedontheRHsideofthefrontcontrolconsole
(redlever)(seeFigure5).
Thethrottleisusedtocontrolenginespeed.Moving
thethrottleleverforwardwillincreaseenginespeed
andmovingthethrottlelevertotherearwilldecrease
enginespeed.Movingthethrottleforwardintothe
detentisfullthrottle.
FrontReference/SpeedControlBar
Locatedinfrontofthemotioncontrollevers(see
Figure5).
Thefrontreference/speedcontrolbarcontrolsthe
maximumforwardspeedandisinnitelyvariable
fromapproximately4–8mph(6–13km/hr).
ParkBrakeLever
Locatedonleftsideofunit,justtothefrontofthe
LHmotioncontrollever(seeFigure5).
Thebrakeleverengagesaparkingbrakeonthedrive
wheels.
Note:TheLCDindicatorappearsinthemessage
displayonthefrontconsolewhentheparkbrakeis
engaged(seeFigure5andFigure7).
Toengagethebrake,pulltheleverrearward.
Torelease,pushtheleverforward.
Whenparkingonasteepslope,thewheelsmustbe
chockedorblockedinadditiontothebrakebeing
engaged.Theunitmustbetieddownandbrake
engagedwhentransporting.
Parkbrakemustbedisengagedbeforemovingmotion
controloutofneutralorenginewillkill.
IgnitionSwitch
LocatedontheLHsideofthefrontcontrolconsole
(seeFigure5).
Theignitionswitchisusedtostartandstopthe
engine.Theswitchhasthreepositions“OFF”,“ON”
and“START”.Insertkeyintoswitchandrotate
clockwisetothe“ON”position.Rotateclockwiseto
thenextpositiontoengagethestarter(keymustbe
heldagainstspringpressureinthisposition).Allow
thekeytoreturntothe“ON”positionimmediately
aftertheenginestarts.
Figure6
1.Off3.Start
2.On
17
