Operation
ProductOverview
g238873
Figure3
1.ECSHandles3.FuelCap
2.Controls4.BladeSpacers
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Controls
Note:Becomefamiliarwithallthecontrolsbefore
startingtheengineandoperatingthemachine.
OperatorPresenceControl(OPC)
Levers
Locatedontheupperhandleassemblydirectlyabove
thehandlegrips.
Whentheseleversaredepressed,theOPCsystem
sensesthattheoperatorisinthenormaloperator's
position.Whentheleversarereleased,theOPC
systemsensesthattheoperatorhasmovedfromthe
normaloperatingpositionandtheenginemustbegin
shutdownifeitherthespeedcontrolleverisnotinthe
neutralpositionorthePTOisengaged(seeFigure4).
g217809
Figure4
LeftECSHandleShown
1.NeutralLockLatch/ParkBrakeLatch
2.DriveLever
3.Handlegrip
4.OPCLever
