Explorer Technology Group DLV50 - Page 13

2.5.2.3 Graph:
Select to view graphical analysis of current HYD string.
2.5.2.4 Limits:
Select to view, remove or edit the high and low threshold limits (specific gravity and temperature) for
the string.
2.5.2.5 -> Flash USB:
Select to export the current HYD string to a .bdf file to a USB flash drive connected to the DLV50 USB
port. This file can later to transferred to a PC and opened with Winmeter 5.0 software.
2.5.2.6 -> Print IRDA:
Select to print the current HYD string to IRDA compatible printer.
2.5.2.7 Delete String:
Select to delete all HYD data in the current HYD string.
This process cannot be undone!
A:008 1.217 72.3
1.1
1.2
1.3
BACK
T/SG
