Explorer Technology Group DLV50 - 2.4.2 VDC Mode Sub-Menu Options

Reading 001 “+2.023” is highlighted in blue to show it is below the low threshold voltage of string A.
Reading 004
“2.423” is highlighted in red to show it is above the high threshold voltage of string A.
Threshold levels are optional and editable.
To scroll through all voltage readings in String A, use the “UP” and “DOWN” keys.
2.4.2 VDC Sub-Menu
To enter the VDC sub-menu press the right soft key (below “MENU”).
VDC Sub-Menu Options:
Use the up/down keys to highlight the appropriate option then push the right soft key (below
“ENTER”) to select that option.
There are 7 options to select from the VDC sub-menu:
Add/Delete
Statistics
Graph
Limits
->Flash USB
->Print IRDA
Delete String
Add/Delete
Statistics
Graph
Limits
-> Flash USB
-> Print IRDA
Delete String
BACK
ENTER
VDC
String A:048
