6.0 Uploading Hydrometer Data to the DLV50
6.1 Transferring Data from a DMA35 to the DLV50
For the DMA35:
(i) Turn the DMA35 ON.
(ii) Use the “EXPORT ALL” function to initiate the data transfer by pushing the following
buttons on the DMA35 in sequence:
“Menu” –> “OK” –> “Export” –> “OK”.
(iii) Line up the IR windows of the DMA-35 and DLV50.
For the DLV50:
(iv) From the “Main Menu” select “HYD Mode”.
(v) Select the required HYD string (A->H) .
(vi) Select “Menu”.
(vii) Select “Upload New”.
During the data transfer process, ALL existing data in the selected HYD string of
the DLV50 will be erased and/or over-written!
NOTE:
IRDA data transfer will take 5 to 20 seconds depending on file size.
NOTE: During the IRDA data transfer, the DMA35 will show the status of the
connection and then transfer progress.
NOTE: Only the first 256 readings stored in the DMA35 hydrometer can be
uploaded to the DLV50.
