Explorer Technology Group DLV50 - Page 9

2.4.2.1 Add/Delete:
Select to measure/store, delete or insert DC cell voltages.
Refer to
Taking a DC Voltage Measurement for additional instructions.
2.4.2.2 Statistics:
Select to view statistics for the current VDC string.
2.4.2.3 Graph:
Select to view graphical analysis of current VDC string.
+0.000
048 +2.023 VDC
047 +2.227 VDC
046 +2.237 VDC
045
+2.423 VDC
044 +2.223 VDC
BACK
MENU
A:048 Sum:102.3
Cell Voltage:
Sum: 102.3
Avg: 2.025
Max: 2.473 [023]
Min: 1.964 [018]
BACK
VDC String A:048
A:008 +2.323V
1.9
2.2
2.5
BACK
