(v) Connect the voltage probes to the cell terminals.
The DLV50 automatically detects that it is connected to a cell and begins measuring the cell
voltage. When the measurement is stable (within +/- 0.005 VDC) the DLV50 automatically
beeps and the reading is held on the display until the probes are removed from the cell.
(vi) Remove the voltage probes from the cell terminals.
The reading is held on the display until the probes are removed. After approximately (1)
second the DLV50 stores the reading, adds the reading to the sum of string cell voltages and
increments to the next reading.
(vii) Repeat steps (iv) and (v) until all cell voltages in the string have been measured.
“H” displayed and
readings “held” on
display until probes are
removed from cell.
Sum of cell voltages
(102.3VDC) for the
selected string
.
Current string (A) and
number of readings
(48).
Selected reading (048)
+2.267
048 +2.023 VDC
047 +2.227 VDC
046 +2.237 VDC
045
+2.423 VDC
044 +2.223 VDC
BACK
MENU
A:048 Sum:102.3
H
Sum of cell voltages
(104.6VDC) for the
selected string
.
Current string (A) and
number of readings
(49).
Selected reading (049)
+0.000
049 +2.223 VDC
048 +2.023 VDC
047 +2.227 VDC
046 +2.237 VDC
045
+2.423 VDC
BACK
MENU
A:049 Sum:104.6
