7
G-10
R
SPECIFICATIONS
MODEL
G-10 MINI CONTROL 1GR G-10 MINI CONTROL 2GR
Steam wand 1 unit 1 unit
Hot water outlet 1 unit 1 unit
Temperature control Regulated by pressure switch Regulated by pressure switch
Temperature control by group No No
Programmed via display No No
Dispensing system for tall cups Optional Optional
Energy saving mode No No
Height, width, depth (mm) 530, 460, 590 530, 460, 590
Boiler volume (l) 6 6
Power supply 230V 1N~ 2770 W 50/60 Hz
230V 1N
~ 2780 W 50/60 Hz
Water connection Female 3/8" thread Female 3/8" thread
Machine weight (kg) 36.05 41.00
Steam boiler operating pressure Between 0.8 and 1.2 bar Between 0.8 and 1.2 bar
Ambient noise < 70 db < 70 db
G-10 MINI CONTROL
TECHNICAL SPECIFICATIONS
Accessories
MODEL
2-spout porta-
filter
1-spout porta-
filter
55-cm inlet
hose
Cleaning
membrane
Drainage tube
(150 cm)
MINI 1GR 1 unit 1 unit 1 unit 1 unit 1 unit
MINI 2GR 1 unit 1 unit 1 unit 1 unit 1 unit
