ZIRCON
13
Model A B C D
ZIRCON MINI 1Gr 530 mm 460 mm 590 mm 74 mm
ZIRCON MINI 1Gr Tall Cup 530 mm 460 mm 590 mm 124 mm
ZIRCON MINI 2Gr 530 mm 460 mm 590 mm 74 mm
ZIRCON MINI 2Gr Tall Cup 530 mm 460 mm 590 mm 124 mm
A
B
C
D
DIMENSION SKETCH
ZIRCON MINI CONTROL
