ZIRCON
15
Model A B C D
ZIRCON 3GR 530 mm 980 mm 590 mm 74 mm
ZIRCON 3GR Tall Cup 530 mm 980 mm 590 mm 124 mm
ZIRCON 3Gr Boilers 530 mm 980 mm 590 mm 74 mm
ZIRCON 3Gr 4 Boilers
Tall Cup
530 mm 980 mm 590 mm 124 mm
A
C
D
B
DIMENSION SKETCH
ZIRCON DISPLAY CONTROL 3GR
