ZIRCON
23
2
4
6
8
10
1
3
5
7
9
Check that the bean hopper (2) is correctly tted in place.
Lift up the bean hopper lid (1), ll the bean hopper (2) with coffee beans and close it again.
Open the bean stop (3) to the position that allows the coffee beans getting into the grinder.
ESPRESSO MACHINE WITH BUILT-IN GRINDER
Operations before starting up the coffee grinder
Pos PART NAME
1 Bean hopper lid
2 Bean hopper
3 Bean stop
4 Grinding adjustment disk
5 Dosage device lid
6 Dosage device
7 Grinder on/off switch
8 Dosage lever
9 Coffee tamper
10 Ground coffee outlet
How to obtain a grinded coffee dose
Place the porta lter under the ground coffee outlet (10)
Pull from the lever (8) towards you in order to obtain a coffee dose and then release the lever.
Place the porta lter under the coffee tamper (9) and push it upwards in order to compact the coffee.
