CHAPTER 27
PAGE 9
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
27-00-02 Bellcranks
Removal/Installation
Refer to Figure 8.
1 Remove the respective access panels.
2 Remove the adjacent control rods per Chapter 27-00-01.
3 Remove the M5 attachment bolt (2).
4 Remove the bellcrank.
5 Reverse procedure to install the bellcrank using sufficient
washers (min. 2) at the nut side of the bolt to cover the shank
(except the rocker type bellcrank: use only one washer on
each side). Replace the selflocking nuts. Observe the first
Note of Chapter 27-00-00 and Figure 3. To ensure installa-
tion of the elevator rocker type bellcrank in correct direc-
tion this bellcrank is marked by an "F" which indicates the
front side (refer to Detail A of Figure 8).
