CHAPTER 73
PAGE 4
MAINTENANCE MANUAL EXTRA 300SC
PAGE DATE: 1. August 2014
73-20-11 Throttle Control Cable
The throttle control cable is a push-pull type cable connect-
ing the throttle control lever (4, Figure 3) with the throttle
actuator (1, Figure 4).
Refer to chapter 20 for general information about handling
control cables.
Removal
Refer to Figure 4, Sheet 1 or 2 depending on exhaust system
installed and Figure 3.
1 Ensure master switch is off.
2 Remove engine cowling per chapter 71.
3 Remove main fuselage cover per chapter 53.
4 Remove cotter pin, castle nut, washers and bolt from the
rod end (2, Figure 4) to throttle actuator (1) attachment.
5 Loosen counter nut and remove the rod end from the throt-
tle control cable.
6 Remove rod end counter nut and throttle control cable pro-
tective swivel and wiper seal.
7 Remove clamp block (3, Figure 4) attachment bolt(s).
8 Remove clamp block from the throttle control cable.
9 Remove the tiedown straps or the cushioned clamp (4, Fig-
ure 4) in the engine compartment.
10 Cut safety wires and remove fire sleeve from the throttle
control cable.
11 Remove 4 bolts and firewall sealant of the clamp sheets
(Figure 2) positioned at the firewall breakthrough.
12 Mark throttle control cable routing and positions of the cable
ties and remove the cable ties in the cabin area.
13 Remove cotter pin, castle nut, washers and bolt and remove
the rod end (3, Figure 3) from the throttle control lever (4).
14 Loosen counter nut and remove the rod end from the throt-
tle control cable.
