USER PARAMETERS
Chapter 7
Parameter
Function
Adjustment
Keys
Value
Con rmation
Key
Display D2 Display D1
0 Act. /deact. weekly programmer 2 o 3 ON/OFF 5
1 Time 1st switch-on 2 o 3 OFF or from 00:00 to 23:50 5
2 Time 1st switch-o 2 o 3 OFF or from 00:00 to 23:50 5
3
Ign./switch-o consents for the various days 2 o 3 ON/OFF 1, ON/OFF 2, ... ON/OFF 7 5
4 Installer parameter 2 o 3 00 5
5 Time 2nd switch-on 2 o 3 OFF or from 00:00 to 23:50 5
6 Time 2nd switch-o 2 o 3 OFF or from 00:00 to 23:50 5
7 Ign./switch-o consents for the various days 2 o 3 ON/OFF 1, ON/OFF 2, ... ON/OFF 7 5
8 Time 3rd switch-on 2 o 3 OFF or from 00:00 to 23:50 5
9 Time 3rd switch-o 2 o 3 OFF or from 00:00 to 23:50 5
A Ign./switch-o consents for the various days 2 o 3 ON/OFF 1, ON/OFF 2, ... ON/OFF 7 1
Let’s suppose that the weekly programmer function is to be used and 3 time periods are to be used in the
following way:
1st time span: from 08:00 to 12:00 every day of the week excluding Saturday and Sunday
2nd time span: from 15:00 to 22:00 only Saturday and Sunday
3rd time span: not used
Let’s set the weekly programmer.
Parameter 0 (D2=0 ( ashing); D1=ON)
Use buttons 2 and 3 to activate the weekly programmer by setting the value at ON.
Parameter 1 (D2=1 ( ashing); D1=E.g. “08:00”)
Use buttons 2 or 3 to set “08:00”, which corresponds to the switch-on time of the 1st time span. To con rm
and continue programming, press button 5.
Press button 4 to go back to the previous parameter.
Parameter 2 (D2=2 ( ashing); D1=E.g. “12:00”)
Use buttons 2 or 3 to set “12:00:”, which corresponds to the switch-o time of the 1st time span. To con rm
and continue programming, press button 5.
Press button 4 to go back to the previous parameter.
Parameter 3 (D2=3 ( ashing); D1=OFF1)
Activate the  rst time span for every day of the week except Saturday and Sunday. To do this use keys 2
and 3 in the following way:
a. key 3 - scroll the various days
b. key 2 - enable/disable (ON/OFF) the 1st time span for that day
Example:
Day Initial value Function key 2 Final value Function key 3
MONDAY OFF1 OFF1 to ON1 and vice versa ON1 (time active) Go to next day
TUESDAY OFF2 OFF2 to ON2 and vice versa ON2 (time active) Go to next day
WEDNESDAY OFF3 OFF3 to ON3 and vice versa ON3 (time active) Go to next day
THURSDAY OFF4 OFF4 to ON4 and vice versa ON4 (time active) Go to next day
FRIDAY OFF5 OFF5 to ON5 and vice versa ON5 (time active) Go to next day
SATURDAY OFF6 OFF6 to ON6 and vice versa OFF6 (time deactivated) Go to next day
SUNDAY OFF7 OFF7 to ON7 and vice versa OFF7 (time deactivated) Go to next day
