Extraflame HP 22 - Operation and Logics

ENGLISH
OPERATION AND LOGICS
IGNITION
Once you have checked the "basic instructions" listed above, press the
for more than two seconds to turn on the generator.
15 minutes are available for the ignition phase. After ignition and having reached the control temperature, the generator stops the ignition
phase and passes to STARTING.
STARTING
During the start-up phase, the generator stabilises combustion, increasing it progressively, then switching to WORK mode.
WORK
During the work phase, the generator reaches the set power; see following item.
ADJUSTMENT SET POWER
Set the operating power from 1 to 5.
Power 1 = minimum level - Power 5 = maximum level.
ADJUSTMENT SET TEMPERATURE H2O
Set the boiler temperature between 65 - 80°C .
PUMP OPERATION
The pump activates water circulation when the in the generator the t° of the water reaches 60°C. As the pump always functions above 60°, an
always open heating area is recommended to make product functioning increasingly uniform, preventing overheating blocks. Normally this
area is dened “Safety zone”.
BURNING POT CLEANING
At pre-set intervals the generator performs the brazier cleaning, switching the machine o.
When the cleaning phase is nished, the generator will re-start automatically and continue its work back to the power level selected.
MODULATION and H-OFF
As the water temperature approaches the set point, the boiler starts to modulate automatically bringing itself to the minimum power.
If the temperature increases beyond the set point, it will automatically switch o indicating HOFF and will automatically go back on when
the temperature drops below the set point.
SWITCHOFF
Press key 1 for three seconds.
When the operation has been performed, the appliance automatically enters the switch- o phase, blocking the supply of pellets.
The ue gas exhaust motor will remain on until the generator temperature has dropped below the factory parameters.
REIGNITION
The genertor can be re-ignited both automatically or manually, when the cooling cycle conditions and the preset timer have been satised.
DO NOT USE ANY INFLAMMABLE LIQUIDS FOR IGNITION!
DO NOT ALLOW THE BAG OF PELLETS TO COME INTO CONTACT WITH THE HOT GENERATOR!
IN THE EVENT OF CONTINUOUS NO IGNITION, CONTACT AN AUTHORISED TECHNICIAN.
18
