INDICATOR LIGHTS
LED indicator
light
Meaning Description
Weekly Programmer function
This LED is on/off when
Weekly programmer is on/ off.
For all the
settings regarding this function, see the section
Weekly programmer .
Room Thermostat function
This LED is on/
off
when the room temperature is lower/higher
than the temperature set.
To modify the temperature setting, use buttons 2 and 3 during
normal operation.
Not used Not used
Spark plug deactivation
This LED is on/off when the spark plug is active/inactive.
To reactivate the spark plug, contact an authorised
technician.
Flue gas motor operation
This LED is on/off when the flue motor is running/not running.
Pump operation
This LED is on/off when the pump is running/not running.
Pellet load motor operation
The LED is on/off when the pellet loading motor is
active/deactivated.
During normal operation, this LED flashes intermittently.
Does not indicate any operation.
This LED must stay off.
Indicates the status of outputs OUT3
and OUT4 on the basis of the external
thermostats ING1 and ING2.
If on, the LED indicates that the prioritise output is
operational (OUT4).
If flashing, the LED indicates that the secondary output is
operational (OUT3).
If off, the LED indicates that the 2 outputs are off.
Indicates the status of automatic
brazier cleaning
The LED is flashing/on when automatic brazier cleaning is
active/deactivated.
Indicates the remote control signal is
being received
The LED is on
during communication between the remote
control and the stove.
