DIVINA PLUS DISTRIBUTED HEATING
Chapter 6
DIVINA PLUS DISTRIBUTED HEATING
DIVINA PLUS
The DIVINA PLUS model is equipped with two pipe outlets situated on the back of the stove that allow the
heat produced by the stove to be distributed to other rooms. For this purpose, as you can see in the photo
below, we recommend using pipes with the following characteristics:
Internal diameter 80 mm
Insulated pipes (thermal insulation)
The pipe length connected to each opening must not be longer than 2 m.
MAXIMUM PIPE
LENGHT 2 METERS
MAXIMUM PIPE
LENGHT 2 METERS
INSULATING MATERIAL
TOSCA PLUS
The Tosca Plus model also has 2 tubes for channelling hot air placed at the rear. Unlike the Divina plus
model, the tubes escape from the top of the product.
Thanks to 2 shutters moved by 2 levers placed inside the pellet tank, which will have to be moved with the
poker supplied, (see illustration above), the Tosca Plus model, also o ers the possibility to decide which
way to direct the hot air.
gure 6.1
gure 6.2
