48
Chapter 13
STOVE CLEANING
FALÒ 1XLP FALÒ 1CP FALÒ 2CP ESMERALDA CLEANING
Maintenance is necessary to ensure the correct function of your stove over time. Failure to do so may
make the device unsafe.
CLEANING THE BURN POT1.
The burn pot must be cleaned every day. To do so.
Remove the burn pot form its compartment and clean
the holes using the poker provided
Remove the ash from the burn pot using a vacuum
cleaner
Vacuum the ash deposited in the burn pot
compartment
USING THE SCRAPERS2.
Cleaning the heat exchangers allows you to maintain a
constant heat yield over time. This type of maintenance
must be carried out at least once a day. For this purpose, use
the special scrapers located in the upper part of the stove,
moving them up and down several times, moving several
times horizontally ( gure 13.28).
CLEANING THE ASH PANS3.
The ash pans should be emptied as needed using a vacuum
cleaner ( gure 13.29).
CLEANING THE HEAT EXCHANGER (monthly)4.
The heat exchangers chamber has to be cleaned once a
month because the ash residue doesn’t let the stove work
properly. To do this, it is necessary to remove the rewall:
Remove the brazier from his frame
Rotate the door latch of 180° like in picture ( gure
13.30).
Take the cast iron and rotate it down.
Remove it from the combustion chamber by pulling it.
Pay attention to the two lateral cast iron levers.
Once the heat exchangers chamber is accessible, scrape with
the ash hook to remove the deposited residues and scrape
o any encrustation. Finally use vacuum cleaner to complete
the cleaning. After that proceed in the inverse order to
reassemble and rotate the door latch of 180° to have it in the
original position.
gure 13.27
gure 13.28
gure 13.29
gure 13.30
