ROOM THERMOSTAT
Chapter 11
ROOM THERMOSTAT
DIGITAL THERMOSTAT INCLUDED
The stove can control the room temperature by means of a digital thermostat whose function is to lower
the heating power to the minimum when a pre-set temperature is reached.
When the stove has been started and has entered normal operating mode, a number (e.g. 21°C ) appears 1.
on display D1 indicating the room temperature.
The thermostat can be set using button 2 or 3. A message appears on the display which alternates the 2.
word “SET” with the temperature set each time one of the buttons is pressed. Pressing 2 decreases the
value and pressing 3 increases it.
Wait until the message “3. SET” disappears from the display.
Use buttons 4 and 5 to adjust the heat setting as desired.4.
When the stove reaches the set temperature, it automatically goes to the minimum operating condition
and LED 1 on display D1 goes o .
If you wish to exclude the digital thermostat, use button 3 to set the temperature to the maximum until
“HOT” appears on display D1.
The same functions can be obtained by remote control.
MECHANICAL THERMOSTAT OPTIONAL
N.B.: Installation must be carried out by an authorized technician.
A thermostat can be placed in a room adjacent to the one in which the stove is installed. Just connect
a mechanical thermostat (like those used for boilers) following the procedure described below. (We
recommend positioning the optional thermostat at a height of 1.50 m above oor level.).
INSTALLING A MECHANICAL THERMOSTAT OPTIONAL
N.B.: Installation must be carried out by an authorized technician.
Switch o the appliance using the master switch on the back of the stove.1.
Disconnect the plug from the power outlet.2.
Referring to the electrical wiring diagram, connect the two thermostat wires to the respective terminals 3.
on the back side of the stove, one red and one black.
MECHANICAL THERMOSTAT WITH STANDBY FUNCTION CAN BE USED WITH
TELEPHONE ACTUATOR
The Standby function is used to further reduce pellet consumption by switching o the stove when the
desired temperature has been reached.
As the temperature drops, the stove will automatically switch on again.
Set the desired temperature using buttons 4 and 5.1.
sing button 2, set the room temperature at the minimum position until display D1 shows “2. LOU” with
“SET” blinking.
While “3. LOU” and “SET” are blinking, press button 1 for three seconds; the display shows “STBY”, which
means that the energy saving function is on.
At this point the thermostat will control the stove as described below:
Thermostat with closed contact D lthe stove switches on and operates at the power set. Display D1
shows “T ON”.
