Extraflame Rosy - LIGHTING AND NORMAL OPERATION

31
PRODUCT FUNCTIONING
Chapter 9
LIGHTING
Before proceeding, check to make sure that:1.
the hopper is loaded 
the combustion chamber is clean 
the burn pot is clean 
the front door and the pellet drawer are closed 
the power outlet is connected 
the switch on the back of the stove is in position 1 
Press button 1 for three seconds; display D1 will show the message “2. AT 08”, with the numbers decreasing
every second. During this stage, the stove carries out an automatic check on the e ciency of each single
electrical component. When this cycle is completed, display D1 shows the message “AC 15” (the number
of minutes for which the stove attempts the lighting stage, decreasing by 1 every minute that passes).
During the products’ first use, even if the tank is full of pellets, it is possible that for the first 15 minutes
the pellets are not distributed to the heating chamber, as the worm screw that loads the pellets is
empty.
If at the end of the 15 minutes the stove has not yet produced a flame, “NO ACC” will appear on the
display.
If steps 1 and 2 are carried out correctly, as soon as the  ame develops the stove enters the start-up 3.
phase (“AU 07”).
After the start-up phase, the stove goes into normal operation: display D1 shows the room temperature 4.
and D2 shows the heat setting.
WARNING!!!
NEVER USE FLAMMABLE LIQUIDS FOR LIGHTING1.
WHEN FILLING, DO NOT BRING THE SACK OF PELLETS INTO CONTACT WITH THE HOT 2.
STOVE
IN CASE OF CONTINUOUS UNSUCCESSFUL IGNITION, CONTACT AN AUTHORISED 3.
TECHNICIAN
NORMAL OPERATION
Once the stove is lit, you can adjust the heat setting using buttons 4 and 5. Pressing button 4 decreases
the heat setting and hourly pellet consumption; pressing 5 increases them. In addition to the feed rate,
the room temperature can be set directly from the control panel. The stove adjusts itself automatically in
relation to the warm air ventilation.
The functioning of the Divina Plus model is similar to that of the other models, with the addition of a 2nd
motor for the channelling. During the stoves’ normal functioning, the second fan will follow the course of
the first fan. It will be possible to enable/disable the functioning of the 2nd motor and gradually increase/
decrease the ventilation of the same as a percentage.
The contents of the hopper should be monitored to prevent the stove going out due to a lack of fuel.
