43
STOVE CLEANING
Chapter 13
CLEANING THE HEAT EXCHANGER (monthly)4.
The heat exchangers chamber has to be cleaned
once a month because the ash residue doesn’t let
the stove work properly. To do this, it is necessary to
remove the rewall:
Remove the brazier from his frame
Rotate the door latch of 180° like in ( gure 13.7).
Take the cast iron and rotate it down.
Remove it from the combustion chamber by
pulling it. Pay attention to the two lateral cast iron
levers.
Once the heat exchangers chamber is accessible,
scrape with the ash hook to remove the deposited
residues and scrape o any encrustation. Finally use
vacuum cleaner to complete the cleaning ( gure
13.9). After that proceed in the inverse order to
reassemble and rotate the door latch of 180° to have
it in the original position.
DOOR, ASH DRAWER AND BURN POT SEALS5.
The seals ensure that the stove is hermetically sealed and consequently that it operates correctly.
The seals should be checked periodically and replaced immediately if worn or damaged.
These operations must be carried out by an authorized technician.
To ensure correct operation, the stove should have general maintenance performed at
least once a year by an authorized technician.
If the power cable is damaged, it must only be replaced by the service centre or by a quali ed technician,
in order to avoid any risks.
gure 13.6
gure 13.7
gure 13.8 gure 13.9
