BlackDiamond 8800 Series Switches Hardware Installation Guide
183
BlackDiamond 8806 Switch
Acoustic Sound (BlackDiamond 8810 Switch with AC Power Supplies)
Sound power in accordance with
EN 300 753 (10-1997)
Sound power
Normal: 70 dBA per ISO 7779
High: 75 dBA per ISO 7779
Declared sound power
Normal: 7.2 belsA per ISO 7779 & ISO 9296
High: 7.7 belsA per ISO 7779 & ISO 9296
Sound pressure in accordance
with NEBS GR-63 Issue 2
Bystander sound pressure
Normal: 64 dBA front side @ 0.6m
High: 67 dBA rear side @ 0.6m
Table 23: BlackDiamond 8806 Switch Technical Specifications
Physical Characteristics
BlackDiamond 8806 chassis Height: 17.47 inches (44.4 cm)
Width: 17.51 inches (44.5 cm)
Depth: 18.12 inches (46.0 cm)
Weight (empty): 63.75 lb (29.0 kg)
Weight (fully loaded): 153 lb (69.5 kg)
BlackDiamond 8806 fan tray
Weight: 4.75 lb (2.2 kg)
Minimum fan speed: 500 RPM
Maximum fan speed: 6000 RPM
BlackDiamond 8806 power
supply
Weight: 7 lb (3.2 kg)
BlackDiamond 8806 PSU/Fan
Controller
Weight: 1.75 lb (.79 kg)
Safety Standards
North American Safety of ITE UL 60950-1:2003 1st Ed., Listed Device (US)
CSA 22.2#60950-1-03 1st Ed.(Canada)
Complies with FCC 21CFR 1040.10 (US Laser Safety)
CDRH Letter of Approval (US FDA Approval)
NOM/NYCE (Mexico)
IEEE 802.3af 6-2003 Environment A for PoE Applications
European Safety of ITE EN 60950-1:2001+A11
EN 60825-1+A2:2001 (Lasers Safety)
TUV-R GS Mark by German Notified Body
73/23/EEC Low Voltage Directive
International Safety of ITE CB Report & Certificate per IEC 60950-1:2001 Country Deviations
AS/NZX 60950-1 (Australia /New Zealand)
Table 22: BlackDiamond 8810 Switch Technical Specifications (Continued)
