3 Installing Your 210 or 220 Switch
Safety Considerations for Installing Switches
Pre-installation Requirements
Attaching a 24- or 48-Port Switch to a Rack
Mounting 12-Port Switches
Installing a Switch on a Desktop or Other Flat Surface
Installing Optional Components
Connecting Power to the Switch
Connecting Network Interface Cables
Before you attempt to install or remove an Extreme Networks switch, read the precautions in Safety
Considerations for Installing Switches on page 37.
ExtremeSwitching switches fit into standard 19-inch equipment racks.
There are additional mounting options for 12-port switch models. They can be mounted on a wall,
individually in a rack, or side by side in a rack.
The provided rack-mounting brackets attach to the front of the switch and are adaptable to either a
front-mount or mid-mount installation. Optional rear-mounting brackets are also included for four-post
racks or cabinets.
The installation process includes the following tasks:
1 Prepare the site for installing the switch.
See Pre-installation Requirements on page 37.
2 Install the switch in a rack or on a desktop.
See Attaching a 24- or 48-Port Switch to a Rack on page 38 or Installing a Switch on a Desktop or
Other Flat Surface on page 48.
For 12-port switch models, see Mounting 12-Port Switches on page 39.
3 Install optional optical transceivers.
See the instructions in Installing Optional Components on page 49.
4 Connect power to the switch.
See Connecting Power to the Switch on page 50.
5 Connect network interface cables.
See Connecting Network Interface Cables on page 50.
6 Perform initial network connection and configuration.
See Basic Configuration for Your Switch on page 60.
ExtremeSwitching 210 and 220 Series Switches: Hardware Installation Guide 36
