Figure 39: Dual-Mount: Attaching the Connecting Brackets to Each Other
The switches can now be handled as if they were a single unit, as shown in Figure 40.
Figure 40: Two Switches Connected to Each Other for Dual Mounting
6 Attach the switches to the rack using rack-mounting hardware (not provided).
After the switches are securely in place, install optional components using the instructions in Installing
Optional Components on page 49.
Installing Your 210 or 220 Switch
ExtremeSwitching 210 and 220 Series Switches: Hardware Installation Guide 45
