14 XTP II CrossPoint Series • Installation
The matrix switcher LAN port and the LAN ports on the input
and output boards support both 10 Mbps (10Base-T — Ethernet)
and 100 Mbps (100Base-T — Fast Ethernet), half-duplex and full
duplex Ethernet connections. Both Ethernet speeds require CAT 5e
cable at minimum.
Matrix switcher and XTP board LAN cables
The LAN ports require CATx, crossover or patch cables.
XTP board XTP cables
ATTENTION:
• Do not connect these boards to a computer data or
telecommunications network.
• Ne connectez pas ces cartes à des données informatiques
ou à un réseau de télécommunications.
• Do not use Extron UTP23SF-4 Enhanced Skew-Free AV
UTP cable or STP201 cable to link the XTP products.
• N’utilisez pas le câble AV Skew-Free UTP version améliorée
UTP23SF d’Extron ou le câble STP201 pour relier les
produits XTP avec les émetteurs.
• To ensure FCC Class A and CE compliance, STP cables
and STP connectors are required.
• An de s’assurer de la compatibilité entre FCC Classe
A et CE, les câbles STP et les connecteurs STP sont
nécessaires.
Extron recommends using the following practices to achieve
full transmission distances up to 330 feet (100 m) and reduce
transmission errors.
Use the following Extron XTP DTP 24 SF/UTP cables and
connectors for the best performance:
XTP DTP 24/1000
Non-Plenum 1000' (305 m) spool 22-236-03
XTP DTP 24P/1000 Plenum 1000' (305 m) spool 22-235-03
XTP DTP 24 Plug Package of 10 101-005-02
If not using XTP DTP 24 cable, at a minimum, Extron recommends
24 AWG, solid conductor, STP cable with a minimum 400 MHz
bandwidth.
Terminate cables with shielded connectors to the TIA/EIA T568B
standard only (patch cables, see gure # on the previous page).
Limit the use of more than two pass-through points, which may
include patch points, punch down connectors, couplers, and
power injectors. If these pass-through points are required, use
shielded couplers and punch down connectors.
