43XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit to Endpoint)
Response (Endpoint to Unit to Host)
Additional Description
Horizontal shift (available for endpoint input 1 only)
Specify a horizontal position
E
I
X!
*
X^
HCTR
}
HctrI
X!
*
X^]
Set input
X!
horizontal position to
X^
.
Increment right
E
I
X!
+HCTR
}
HctrI
X!
*
X^]
Shift the
X!
input right.
Decrement left
E
I
X!
–HCTR
}
HctrI
X!
*
X^]
Shift the
X!
input left.
View the horizontal position
E
I
X!
HCTR
} X^]
Show the horizontal position.
Vertical shift (available for endpoint input 1 only)
Set a specic vertical position
E
I
X!
*
X^
VCTR
}
VctrI
X!
*
X^]
Set input
X!
vertical position to
X^
.
Increment up
E
I
X!
+VCTR
}
VctrI
X!
*
X^]
Shift the
X!
input up.
Increment down
E
I
X!
–VCTR
}
VctrI
X!
*
X^]
Shift the
X!
input down.
View the vertical position
E
I
X!
VCTR
} X^]
Show the vertical position.
Analog input presets
NOTE: Analog input presets are a set of variables that can be saved. For the complete list, see the XTP II CrossPoint Series User Guide.
Save an analog input preset
X!
*1*
X&
, Spr
X!
*1*
X&]
Command character is a comma.
Recall an analog input preset
X!
*1*
X&
. Rpr
X!
*1*
X&]
Command character is a period.
NOTE:
X!
= Input number 01 – 16, 32, or 64
X^
= Shift 0 through 65535
X&
= Analog input preset 1 through 8
