EZA ECB Series - Page 11

9
MODEL
ECB35-112
ECB35-124
ECB35-148
ECB35-212
ECB35-224
ECB35-248
Output Protection
Short Circuit / Overload / Over Temperature / Over Voltage Protection
Environment
Working Temp.
-20～+60°C; refer ECB35 power de-rating curve
Storage Temp.
-40～+70°C
Relative Humidity
Max. 90%, non-condensing
Safety & EMC
Safety Standards
Certified UL 458
(UL only for hardwire)
----
Certified EN60950-1
EMC Standards
Certified FCC Class B
②
Certified EN 55014-1, EN 55014-2;
EN 61000-3-2, -3-3; EN61204-3;
EN 61000-6-1, -6-2, -6-3, -6-4
IEC 61000-4-2, 3, 4, 5, 6, 11
E-Mark
----
Certified CISPR 25; ISO 7637-2
Control & Signal
LED Indicator
Input voltage level, faulty status
Remote Control
CR-6, CR-8 and CR-10
Others
Dimension (WxHxD)
283x128x496 mm / 11.14x5.04x19.53 inch
Weight
10 kg
Cooling
Load & Thermal control fan
Communication Port
RS-232 (RJ-11 type connector), Ethernet (Optional)
Note
The specifications are subject to change without prior notice. All the test
environments are conducted under the rated power operation conditions.
① Please refer to P.8 Transfer-Time Table.
② EN 55014-1, EN 55014-2 Class B: output cable less than 2 meters.
De-rating Curve
Figure 1. ECB2500 de-rating curve Figure 2. ECB3500 de-rating curve
