EZA ECB Series - ALARM, SAVING AND INTERVAL SETTINGS; Overload Alarm Configuration; Shut-down Retry Settings; Saving Level and Interval

40
EN
Note
The value of the voltage set for the “UV Alarm” should be equal to or
higher than the value set for “UVP” or else the unit will shut-down
without any audible warning.
6. O/P Voltage <FUNC5>：Setting the ECB-series output voltage on the inverter
operation.
Default = 110 VAC @ 110 V Model, 230 VAC @ 230 V Model
Model
Setting value range
110 V
97 VAC ~ 123 VAC
230 V
194 VAC ~ 246 VAC
Table 34. O/P Voltage <FUNC5>
7. RS-232 Baud rate <FUNC6>：
Default setting：4800
Setting Menu
SETT<value>
RS-232
Baud rate
0
1200
1
2400
2
4800
3
9600
4
19200
Table 35. RS-232 Baud rate <FUNC6>
8. O/P Frequency <FUNC7>：Setting the ECB-series output frequency on the
inverter operation.
Default = 60 Hz @ 110 V Model, 50 Hz @ 230 V Model.
Model
Setting value range
110 V
47 Hz ~ 63 Hz
230 V
47 Hz ~ 63 Hz
Table 36. O/P Frequency <FUNC7>
9. Sync Frequency <FUNC8>：If a generator is distorted. The output waveform
(too low frequency) is used as AC source, the allowed frequency window for
the incoming AC power can be enlarged.
Example1：
AC input = 230 VAC / 50Hz, User setting Value= 7Hz
When the ECB-series “Output frequency” is within The Range of 43 Hz~57
Hz, the internal transfer relay will close. When the output frequency is less
than 43 Hz or more than 57 Hz, the internal transfer relay will still open.
