ATR833A / P/N 833A-(xxx)-(1xx)
Operation and Installation
10
Dokument-Nr.: 01.1411.010.71e / Revision: 3.00
Display Meaning Remark
ACT Fixed label for active
frequency
SBY Label for standby frequency,
when no dual watch activated
Dual watch mode allows
intermittent monitoring of
standby frequency activity
DW Label for standby frequency,
when dual watch mode
activated
Dual watch mode allows
intermittent monitoring of
standby frequency activity
118.000 Active Frequency Frequency used for
transmissions and
receptions
124.910 Standby frequency May be monitored in dual
watch mode
RX Receiving on this frequency Usually on active
frequency; can also happen
on standby frequency when
dual watch activated
TX Transmitting on active
frequency
PTT pressed
Te Transmission ended
automatically after 2 minutes
continuous transmission
Press PTT shortly to
re-enabel transmissions
VOL 03 Volume level for receiving
SQL 03 Squelch level Radio signal strength
threshold required for
reception; suppresses
noise and weak/distant
transmitter
DIM 07 Display brightness
VOX 05 Vox level Speech level that activates
the intercom
DWM -2 Dual watch mute Reduction in volume for
dual-watch-reception on
standby frequency
INT 04 Intercom volume
