ATR833A / P/N 833A-(xxx)-(1xx)
Operation and Installation
17 Dokument-Nr.: 01.1411.010.71e / Revision: 3.00
When having the channel selection configured for 8.33 kHz steps, the
frequency is input in three steps:
123
.450
→
123.
4
50
→
123.4
50
When having the channel selection configured for allowing 25 kHz
channels only, the frequency is input in two steps:
123
.450
↔
123.
450
2.5.3 Recall a Frequency from the User Memory
To access the user memory frequency list, press once, and select
one of the 100 memory entries with the turn knob. The
selected memory entry substitutes the former standby frequency.
In the lower left corner of the display, the number of the memory entry
selected is indicated by [MEM xx] (with xx = 00 … 99).
If a name has been provided by the user for this memory entry, it is
displayed next to the memory entry number during the selection process.
ACT
123.450
SBY
121.270
MEM
17
HAMBURG
interchanges the newly set standby frequency and the former active
frequency, and leaves the memory list menu.
In order to speed up the entering of new frequencies, it is
possible to configure the radio to allow entering of those
frequencies only that are used with 25 kHz channel width.
Please refer to chapter 3.1
for information on this
configuration.
However, when choosing this option, please keep in mind to
re-enable 8.33 kHz channel selection before
flying into areas
where 8.33 kHz channels are used.
Entry number (Range: 00 – 99)
