F.u.n.k.e. ATR833A-OLED - 4 Installation; Advices and Tips; Telecommunication Data; Scope of Delivery

ATR833A / P/N 833A-(xxx)-(1xx)
Operation and Installation
29 Dokument-Nr.: 01.1411.010.71e / Revision: 3.00
4 INSTALLATION
4.1 Advices and Tips
The following suggestions should be considered before installing
The assigned installation company could perform wiring. For diagrams
refer to section 4.7 Wiring.
4.2 Telecommunication Data
The following data may be required when applying for the aircraft radio
station license:
Manufacturer: f.u.n.k.e. AVIONICS GmbH
Type Designation: ATR833A
EASA Number: EASA.21O.270
Transmitter Power Output: 6 W
Frequency: 118,000 – 136,975 MHz
Emission Designator:
6k00A3E for 25khz channel spacing
5k00A3E for 8,33kHz channel spacing
4.3 Scope of delivery
Part Number Description
ATR833A ATR833A - VHF communication transceiver
SSATR2 Connector
(Only if no cable set was ordered)
MB800A2 Mounting Block Set
01.1411.010.71e User Manual „Operation and Installation“
EASA Form 1
