ATR833A / P/N 833A-(xxx)-(1xx)
Operation and Installation
27 Dokument-Nr.: 01.1411.010.71e / Revision: 3.00
3.5 Microphone Input Sensitivity (MLS/MLD/MRS/MRD)
3.5.1 MLS – Left Standard microphone Input Sensitivity
3.5.2 MLD – Left Dynamic Microphone Input Sensitivity
3.5.3 MRS – Right Standard Microphone Input Sensitivity
3.5.4 MRD – Right Dynamic Microphone Input Sensitivity
ACT
123.450
SBY
118.910
MLS
04
ACT
123.450
SBY
118.910
MRS
04
ACT
123.450
SBY
118.910
MLD
04
ACT
123.450
SBY
118.910
MRD
04
The following microphone inputs are available:
Microphone Input
Left Right
standard MLS MRS
dynamic MLD MRD
With VOX set to 5 previously, select the microphone to adjust with .
For each microphone input, with running engine speak with normal
volume into the selected microphone, and use the rotary knob
to adjust the sensitivity, so that the bar reaches the middle of the
scale, as depictured above.
Per microphone input a maximum of two parallel installed microphones
may be connected. (see 4.6.1)
Every microphone input’s sensitivity can be individually
configured, in
order to achieve equal volume with all
microphones.
