5.2 Technical Data
GENERAL
COMPLIANCE ETSO-2C37e,ED-23B Class 4, 6
ETSO-2C38e,ED-23B Class C, E
STANDARD TSO-C37d, RTCA DO-186A Class 4, 6
TSO-C38d, RTCA DO-186A Class C, E
DIMENSIONS
Height: 38,5 mm (1,49 in)
Width: 140 mm (5,51 in)
Length: 241 mm (9,49 in) behind the
panel
WEIGHT 1,58 lbs (0,72 kg)
MOUNTING Panel Mounted
TEMPERATURE RANGES
OPERATION
STORAGE
-20 °C ... +55 °C,30 min at +70 °C
-55 °C . . +85 °C
MAX. HEIGHT 50000ft
VIBRATION DO-160D, Cat. S, Vibration Curve M
HUMIDITY RTCA DO-160D, Cat. A
SHOCK
6 G operation
20 G crash safety
RTCA DO-160D ENV.CAT. [C1Z]CAA[SM]XXXXXXZBAAA[TT]M[B3F3]XXA
POWER SUPPLY
13,8 VDC (11 VDC ... 18 VDC)
transmitter: 2,5A
receiver: 0,2A (Standby),max. 0,5A
audio power amplifier: up to 1A
emergency ops, reduced transmitting power
< 11 VDC
POWER CONSUMPTION Standby: 2,8W, transmitting 35W
FUSE external fuse required: 4 A, slow-blow
FREQUENCY RANGE 118,000 MHz .. 136,975 MHz
FREQUENCY STABILITY ±30 ppm at -20 °C .. + 55 °C
COMPASS-SAFE
DISTANCE
30cm
INTERCOM-INPUT
The microphone inputs are connected to the
Intercom input. 100 mVRMS at the microphone
input produce 0,5 W output power at the
Headphone output (300 Ω).
NF (AUDIO) - INPUT 1V/600Ω
