TRT800H / P/N 800ATC-H-(2xx)-(2xx)
Operation and Installation
13
Document-No: 03.2124.010.71e / Revision: 2.10
Value
Meaning
Remarks
Error indicators
PLL
PLL Error
Internal Error
TRX
Transmit Failure
Check antenna and wiring
DC
Low internal voltage
Internal error
FPG
FPGA-Failure
Internal error
BAT
Battery Power too low
maybe battery/generator fault
2.4 Display-Brightness
In active mode (not standby) press ► for 2 s
Display indicates “DIM”  Adjust brightness (DIM) with rotary knob
Return to normal operation: press ► or wait 5 s.
2.5 Flight-ID (FID)
The FID is an identifier required for Mode S Operation. During future
application of flight plans a FID could be assigned on a per flight basis. If
no FID is assigned (today’s normal case) the registration marking of the
aircraft should be used as FID. The FID should not contain dashes or
blanks. The FID must not be confused with the 24-bit Aircraft Address.
2.5.1 Display Flight-ID
Press MODE (repeatedly) until „STBY“ appears
Press and hold ID while a counter is shown beside the active squawk.
During a few seconds Flight Identification is displayed
FID 02
A B C D E F G H
-
