TRT800H / P/N 800ATC-H-(2xx)-(2xx)
Operation and Installation
Document-No: 03.2124.010.71e / Revision: 2.10
4.5.5 Altitude Correction Setup
Altitude correction setup shall be executed by qualified
personnel only!
Pilot and owner are responsible for correctly set altitude
offset values.
The use/setting of altitude correction values is only
necessary in exceptional cases (see 4.4.4 for details)
Altitude correction is based on five interpolation points ( 2000, 10000,
18000, 25000 and 35000 ft).The offset value at each interpolation point
can be adjusted in a range from -100 to + 100ft at each point (10ft steps).
Offset values set to zero at each interpolation point deactivates altitude
correction (default/factory setting).
2. Ensure, the transponder-mode is
„STBY“. If necessary change the
mode by pressing MODE
3. Press ID
A counter is shown at the upper-right
corner. Hold ID till “ALTITUDE
OFFSET” is displayed.
