 GPS receiver is connected and transmits data (if not: “Pos. :no
data” is displayed)
 a valid position is transmitted (if not: “Pos. :wrong data” is
displayed).
While configuration summary page is displayed no new position data will
be processed.
4.3 General settings
4.3.1 ICAO 24-Bit Aircraft Address (AA)
Ask your national aviation authority (e. g. in Germany: LBA, Referat B5,
Department “Verkehrszulassung”) how to obtain the AA. In the case of
aerial sports equipment the contact point would be the respective
associations. Only the assigned AA has to be used and must not be
modified at any time, because a duplicate address would jeopardize the
data surveillance and integrity figures of Mode S.
If no AA is stored, after power on the display shows
“CRADLE OFF” and the transponder operates in Mode A/C.
(Configuration of the AA: see section 4.5.4)
4.3.2 Aircraft Category (AC)
Code
Description
Code
Description
11
Emergency Vehicle
1C
Ultra-Light / Paraglider
12
Service Vehicle
1E
Drone
19
Glider
21
Aircraft (D-Exxx) < 15.500 lbs,
Motor Glider (D-Kxxx)
1A
Balloon & Airship
22
Aircraft
≥ 15.500 lbs,< 75.000 lbs
1B
Paratrooper
27
Rotorcraft
Only one of the Codes mentioned in the table above must
be used.
