F.u.n.k.e. TRT800H-OLED - Cable Plans for Memory Adapters

TRT800H / P/N 800ATC-H-(2xx)-(2xx)
Operation and Installation
22
Document-No: 03.2124.010.71e / Revision: 2.10
3.7.3 Cable plan External Memory EM800
3.7.3.1 Cable plan TRT800EMRS (older version with interface remote)
to S/N 90932013
DSUB 15pol
TRT800H/TRT800A
*
< PIN-5 >
< PIN-12>
< PIN-15>
< PIN-13>
< PIN-7 >
< PIN-2 >
< PIN-6 >
< PIN-1 >
< PIN-9 >
< PIN-8 >
< PIN-14>
TXD
RXD
FLY_GND
SUPP_I/O
GND
open
cable
ends
Remote Binder
Connector
female
white
black
yellow
red
shield
blue
red
brown
GND
+UB
AUTO-ON
(2)(3)
black
white
red
yellow
shield
Binder Connector female
(solder side)
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
D-SUB Connector female
(solder side)
open
cable
ends
1
New interface available
-at TRT800H starting from S/N: 30430109 with SW V5.3
-at TRT800A starting with SW V5.3
2
New TRT800H interface starting from HW 6.0
3
port / function not available at TRT800A
3
4 2
5 1
RMT-LIGHT
GND
RMT-TXD
RMT-SW+UB
RMT-RXD
RMT-TXD
(1)
RMT-RXD
(1)
RMT-SW+UB
(2)(3)
RMT-LIGHT
(2)
GND
(1)
