F.W. Bell 5280 User Manual

STANDARD TRANSVERSE PROBE
Model Number: (5280): STD18-0404
(5270): STH17-0404
Frequency Bandwidth: (5280): 0 to 20 kHz
(5270): 0 to 10 kHz
Offset change with Temperature: ±300 mG / ºC (typical)
Accuracy change with Temperature: -0.05%/ºC (typical)
Operating Temperature Range: 0 to +75ºC (+32 to +167°F)
Storage Temperature Range: -25 to +75ºC (-13 to +167°F)
Model
A
± 0.063”
B
C
D
Material
Corrected
Linearity
Sensitivit
Active Area
Operating
Temp. Range
Temp. stability (typ)
Zero Calibrate
Frequency
Response
STD18-0402 2”
STD18-0404 4”
STH17-0402 2”
STH17-0402 4”
HTH17-0604 4”
HTD18-0604 4”
STB1X-0201*** 1”
0.158”
±.004
0.180”
±.004
.050”
±.005
0.046”
+.000
-.004
0.060”
+.000
-.004
.020”
MAX
0.040”
(NOM)
0.030”
(NOM)
Fiberglass
**see note
ALUMINUM
3003
¾ FH
KAPTON
0.5%/30kG
1.0%/20kG
1.0%/20kG
0.5%/30kG
1.0%/10kG
1X
0.015"
DIA (NOM)
0.025"
DIA (NOM)
0 to +75ºC
(32 to 167°F)
±0.300
Gauss/ºC
(typical)
-0.05
% /ºC
(typical)
±0.200
Gauss /ºC
-0.1% /ºC
DC to 20kHz
DC to 10kHz
DC to 10kHz
DC to 20kHz
DC only
Note: Due to continuous process improvement, specifications are subject to change without notice.
** Prior to late 2006 Transverse Probe Stems were rigid glass epoxy, .150 x .040”. From 2006 to 2014 they were polypropylene, .158 x .045”.
*** Not available for purchase. Existing STB1X-0201 probes can be used with 5200 series meters.
2-4
Figure 2-1
Standard Transverse Probe
