VIPRION LCD Panel
Platform Guide: VIPRION
®
3 - 3
About the LCD menus
To use the LCD menus, you must first put the LCD panel in Menu mode. To
put the LCD panel in Menu mode, press the X button.
After you put the LCD panel in Menu mode, use the Left Arrow, Right
Arrow, Up Arrow, and Down Arrow buttons to select menu options. There
are three menus:
•Options
• System
• Screens
Options menu
The Options menu provides options for adjusting the display properties of
the LCD panel.
Option Description
Heartbeat Turns on (checked) or off (unchecked) the heartbeat
panel on the LCD. This heartbeat does not affect the
failover mechanism of the system.
Backlight Controls the backlight for the LCD panel.
Contrast Sets the contrast of the LCD display.
On Brightness Adjusts the LCD panel backlight brightness.
Off Brightness Controls the brightness of the LCD panel when the
backlight is off.
Table 3.1 The Options menu
