Chapter 3
3 - 4
System menu
The System menu provides options for configuring the management
interface on both clusters and blades. This menu also provides various
options for the hardware.
Option Description Suboptions
Chassis Config Changes the baud rate of
the serial port.
Serial Speed
Select from the following
suboptions:
• 9600
• 19200 (default)
• 38400
• 115200
Cluster Configures the cluster IP
address, netmask, and
default gateway for
managing the cluster.
Cluster Mgmt
Select from the following
suboptions:
• Cluster IP
Configure the cluster IP
address.
• Cluster IP Mask
Configure the netmask.
• Gateway
Configure the default gateway
for managing the cluster.
• Commit
Save your changes.
Configures the
management IP
addresses of the blades
within the cluster.
Cluster Mbrs
Select from the following
suboptions:
• Blade [1-4] Mgmt
• Blade Mgmt IP
Configure the management
IP address of the selected
blade within the cluster.
• Commit
Save your changes.
Table 3.2 The System menu
