Chapter 9
9 - 6
J100 chassis specifications
The following specifications apply to the J100 chassis only.
This platform supports only optics modules provided by F5 Networks.
Specifications are subject to change without notification.
Item Specification
Dimensions
12.2 in. H x 17.4 in. W x 21 in. D (30.9 cm H x 44.2 W x
53.3 cm D) rack-mount chassis
Weight
Fully-loaded system (4 blades, 4 power supplies): 139
lbs (63.0 kg)
Half-loaded system (2 blades, 2 power supplies, 2
blanks): 105 lbs (47.6 kg)
Empty chassis (3 blank cards, 0 power supplies, 0
blades, 1 fan tray, 1 System ID card): 69 lbs (31.3 kg)
Power supply: 4.5 lbs (2.0 kg)
PB100 blade: 14.5 lbs (6.58 kg)
PB200 blade: 14.5 lbs (6.58 kg)
Blank line card: 2 lbs (0.9 kg)
Fan tray: 8.5 lbs (3.9 kg)
System ID card: 0.5 lbs (0.2 kg)
Processor
See blade specifications.
Hard Drive Capacity
See blade specifications.
RAM
See blade specifications.
Power supply type
1 to 4 90VAC to 240VAC AUTO ranging
Input Voltage and
Current
90-240 VAC (AC)
20A per input line (max)
Typical power draw
(fully-loaded chassis)
1700W
Typical heat generated
(fully-loaded chassis)
5800 BTU/hr
Table 9.7 The J100 chassis specifications
