Network interface LED behavior
The appearance and behavior of the network interface LEDs on the
performance blades indicate network traffic activity, interface speed, and
interface duplexity. Table 4.8 defines the behavior for RJ45 copper
interfaces.
Table 4.9 defines the behavior for SFP optic interfaces.
Speed LED Activity LED Link Blade type
Not lit Not lit No link PB100, PB200
Blinking yellow Yellow (with traffic) 10Mbps, half duplex PB100
Blinking yellow Green (with traffic) 10Mbps, full duplex PB100
Solid yellow Yellow (with traffic) 100Mbps, half duplex PB100
Solid yellow Green (with traffic) 100Mbps, full duplex PB100
Solid green Yellow (with traffic) 1000Mbps, half duplex PB100, PB200
Solid green Green (with traffic) 1000Mbps, full duplex PB100, PB200
Table 4.8 RJ45 Copper interface LEDs
Speed LED Activity LED Link Blade type
Not lit Not lit No link PB100
Blinking yellow Yellow (with traffic) 10Mbps, half duplex PB100
Blinking yellow Green (with traffic) 10Mbps, full duplex PB100
Solid yellow Yellow (with traffic) 100Mbps, half duplex PB100
Solid yellow Green (with traffic) 100Mbps, full duplex PB100
Solid green Yellow (with traffic) 1000Mbps, half duplex PB100
Solid green Green (with traffic) 1000Mbps, full duplex PB100
Table 4.9 SFP optic interface LEDs
